Yesterday’s Technology . . . Today!
Taken from the book “Operation and Mechanism of the Linotype and Intertype” by J Ashworth, first published in 1955.
THIS specially-designed TTS Linotype apart from its special high-speed features, is manufactured and equipped on similar lines to the standard Model 48.
Taken from the book “Operation and Mechanism of the Linotype and Intertype” by J Ashworth, first published in 1955.
1, a display slug partially stripped; 2, the control knob of the slug-holding clamp; 3, a slug stripped ready for use; 4, the type metal gauge block; 5, the micrometer gauge, calibrated in thousandths of an inch.
Matt Henderson, of Henderson Printing, 7627 B Hull Street Rd, Richmond, Virginia, USA kindly sent in these logos that he’s been working on recently. Matt is keen to get his hands on more logos that he can turn into high quality artwork.
Higher-resolution versions of these images are available for download in a zip file here: Metal Type Library – Miscellaneous.
This article appeared in “Operation and Mechanism of the Linotype and Intertype, Volume II” by J Ashworth, published in 1955.
The Intertype composing stick attachment includes a special setting stick, similar to a composing stick, for easy hand assembling of lines of matrixes and spacebands, and a special hinged first elevator head for quick insertion and withdrawal of hand-set matrix and spaceband lines.
This photographic postcard, which the seller said probably dated from the 1930s-40s, was recently offered for sale on Ebay.
The following was printed on the reverse of the postcard:
Many thanks to Robin Kenworthy for sending in this article, originally published in a book called “Typographical Printing Surfaces” shortly after 1907. The Graphotype was an early rival to the Monotype system, but had the keyboard and casting system in the one machine.
Robin has a museum-worthy collection of machines, type and matrices as well as an extensive library on the subject of letterpress.
Tony Shaffstall from Indianapolis, Indiana, USA, got in touch with Metal Type to give us details of the Shaffstall Transistor Mat Detector that his father (Everett G Shaffstall) invented.
Tony sent in the patent application (10 pages with some nice illustrations) dating from 1960 and a 1965 copy of the Installation Instructions and Trouble Diagnosis (72 pages).
Chris Johnson contacted Metal Type in November 2007 saying that he was an engineer working for Express Gifts, part of Findel PLC and had been looking after 3 working Intertype Monarchs for the past 11 years. The company had recently acquired a refurbished Intertype C4 to bring the count of working linecasters up to 4! The machines are used to produce slugs of people’s names to manufacture personalised gift items.
The machines all have a Decitek Floppy Disk Drive operating a Fairchild Teletypesetting unit. Chris very kindly sent in the following photographs.
George Finn, an Australian Linotype mechanic, sent in this photograph and details of the restoration project.
This is the oldest machine I have ever worked on. Checking the serial number (22971) against shipping dates, I find that it was shipped in the first half of 1918.
I FOUND this C4 Intertype abandoned at an Historical Preservation Society in Pimpama, just 10 km (6 miles) from where I live.
I asked the Publicity Officer what he could tell me about the machine. He said it was before his time, but that they had owned a number of machines but the rest had been given away, along with all the spare parts.
